Factor 55 Flatlink XXL Winch Shackle Mount

SKU: 00090-06

Vendor Factor 55
Regular price $229.00
Sale price $229.00 Regular price $286.25
Sale Sold out
Unit price
/per
Color:
Grey
Red
Blue
Black
Silver
This is a pre order item. We will ship it when it comes in stock.

Have Questions? Call (417) 501-1190

Total Satisfaction 90-Day Returns

Guaranteed Safe Checkout

Factor 55 Flatlink XXL Winch Shackle Mount

The world’s first foldable winch shackle mount with self centering load spool.

Compatible with wire rope diameters of up to 3/4″ and synthetic rope tube thimbles up to 5/8″ in diameter. Fits shackle pin diameters of 1 1/8″. 7/8″ diameter titanium double shear pin. Minimum breaking strength of 65,000 lbs.

Made in USA.

U.S. Utility Patent No. 9,388,025
Foreign Patents Pending

  • Replace conventional winch hooks with a safer more secure shackle/D-ring
  • Safer recoveries through the practice of Closed System Winching
  • Lightweight – Precision CNC machined 6000 series Military Grade Aluminum
  • No splicing required – double shear pin design
  • Designed for both steel cable and synthetic winch rope eyes
  • Equipped with a shear pin load centering spool for wire rope applications
  • Foldable and stows rattle free against fairleads
  • Integrated EPDM rubber pads for fairlead protection
  • Fits common 7/8 and 1” screw pin shackle sizes (1.0 and 1.125 pin diameters)
  • For synthetic rope diameters up to 5/8 and wire rope up to 1”
  • Available in the Military Specification Hard Anodizing (Mil-A-8625 F Type III) Gray
  • 7/8” diameter double shear pin
  • Max Rated Load: 26,000 pounds
  • Ultimate Strength: 68,000 pounds
  • Weight: 51oz

Selected page contains no content. Add content to this page in the page editor.

Selected page contains no content. Add content to this page in the page editor.

Description

Factor 55 Flatlink XXL Winch Shackle Mount

The world’s first foldable winch shackle mount with self centering load spool.

Compatible with wire rope diameters of up to 3/4″ and synthetic rope tube thimbles up to 5/8″ in diameter. Fits shackle pin diameters of 1 1/8″. 7/8″ diameter titanium double shear pin. Minimum breaking strength of 65,000 lbs.

Made in USA.

U.S. Utility Patent No. 9,388,025
Foreign Patents Pending

  • Replace conventional winch hooks with a safer more secure shackle/D-ring
  • Safer recoveries through the practice of Closed System Winching
  • Lightweight – Precision CNC machined 6000 series Military Grade Aluminum
  • No splicing required – double shear pin design
  • Designed for both steel cable and synthetic winch rope eyes
  • Equipped with a shear pin load centering spool for wire rope applications
  • Foldable and stows rattle free against fairleads
  • Integrated EPDM rubber pads for fairlead protection
  • Fits common 7/8 and 1” screw pin shackle sizes (1.0 and 1.125 pin diameters)
  • For synthetic rope diameters up to 5/8 and wire rope up to 1”
  • Available in the Military Specification Hard Anodizing (Mil-A-8625 F Type III) Gray
  • 7/8” diameter double shear pin
  • Max Rated Load: 26,000 pounds
  • Ultimate Strength: 68,000 pounds
  • Weight: 51oz
